Address Match Interrupt
M30240 Group
Rev.1.00 Sep 24, 2003 Page 269 of 360
2.10.1.5 Related registers
Figure 2.115 shows the memory map of address match interrupt-related registers, and Figure 2.116
shows address match interrupt-related registers.
Figure 2.115: Memory map of address match interrupt-related registers
Figure 2.116: Address match interrupt related registers
000916
000A16
000B16
000C16
000D16
000E16
000F16
001016
001116
001216
001316
001416
001516
001616
Address match interrupt register 0 (RMAD0)
Address match interrupt register 1 (RMAD1)
Address match interrupt enable register (AIER)
Symbol Address When reset
RMAD0 0012
16 to 0010 16 X00000 16
RMAD1 0016 16 to 0014 16 X00000 16
Bit nameBit symbol
Symbol Address When reset
AIER 0009
16 XXXXXX00 2
Address match interrupt enable register
Function
WR
Address match interrupt 0
enable bit
0 : Interrupt disabled
1 : Interrupt enabled
AIER0
Address match interrupt 1
enable bit
AIER1
Nothing is assigned.
In an attempt to write to these bits, write “0”. The value, if read, turns out to
be indeterminated.
b7 b6 b5 b4 b3 b2 b1 b0
WR
Address setting register for address match interrupt
Function Values that can be set
Address match interrupt register i (i = 0, 1)
00000 16 to FFFFF 16
Nothing is assigned.
In an attempt to write to these bits, write “0”. The value, if read, turns out to
be indeterminated.
0 : Interrupt disabled
1 : Interrupt enabled
b0 b7 b0b3
(b19) (b16)
b7 b0
(b15) (b8)
b7
(b23)
