Overview of Interrupts
M30240 Group
Rev.1.00 Sep 24, 2003 Page 346 of 360
4.1.6.5 The NMI interrupt
• As for the NMI interrupt pin, an interrupt cannot be prohibited. Connect it to the Vcc pin if unused.
• Do not get into stop mode or wait mode with the NMI
pin set to “L”.
4.1.6.6 Rewrite the interrupt control register
See section 4.1.3.6 Interrupt Control Rewrite for precautions on writing to the interrupt control regis-
ters.
