RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 159
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (8/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After reset
1-bit 8-bit 16-bit
F0240H Timer RJ control register 0 TRJCR0 R/W –
– 00H
F0241H Timer RJ I/O control register 0 TRJIOC0 R/W
– 00H
F0242H Timer RJ mode register 0 TRJMR0 R/W
– 00H
F0243H Timer RJ event pin select register 0 TRJISR0 R/W
– 00H
F0260H Timer RD ELC register TRDELC R/W
– 00H
Note
F0263H Timer RD start register TRDSTR R/W –
– 0CH
Note
F0264H Timer RD mode register TRDMR R/W
– 00H
Note
F0265H Timer RD PWM function select register TRDPMR R/W
– 00H
Note
F0266H Timer RD function control register TRDFCR R/W
– 80H
Note
F0267H Timer RD output master enable register 1 TRDOER1 R/W
– FFH
Note
F0268H Timer RD output master enable register 2 TRDOER2 R/W
– 00H
Note
F0269H Timer RD output control register TRDOCR R/W
– 00H
Note
F026AH Timer RD digital filter function select register 0 TRDDF0 R/W
– 00H
Note
F026BH Timer RD digital filter function select register 1 TRDDF1 R/W
– 00H
Note
F0270H Timer RD control register 0 TRDCR0 R/W
– 00H
Note
F0271H Timer RD I/O control register A0 TRDIORA0 R/W
– 00H
Note
F0272H Timer RD I/O control register C0 TRDIORC0 R/W
– 88H
Note
F0273H Timer RD status register 0 TRDSR0 R/W
– 00H
Note
F0274H Timer RD interrupt enable register 0 TRDIER0 R/W
– 00H
Note
F0275H
Timer RD PWM function output level control
register 0
TRDPOCR0 R/W
– 00H
Note
F0276H Timer RD counter 0 TRD0 R/W – –
0000H
Note
F0277H
F0278H Timer RD general register A0 TRDGRA0 R/W – –
FFFFH
Note
F0279H
F027AH Timer RD general register B0 TRDGRB0 R/W – –
FFFFH
Note
F027BH
F0280H Timer RD control register 1 TRDCR1 R/W
– 00H
Note
F0281H Timer RD I/O control register A1 TRDIORA1 R/W
– 00H
Note
F0282H Timer RD I/O control register C1 TRDIORC1 R/W
– 88H
Note
F0283H Timer RD status register 1 TRDSR1 R/W
– 00H
Note
F0284H Timer RD interrupt enable register 1 TRDIER1 R/W
– 00H
Note
F0285H
Timer RD PWM function output level control
register 1
TRDPOCR1 R/W
– 00H
Note
F0286H Timer RD counter 1 TRD1 R/W – –
0000H
Note
F0287H
F0288H Timer RD general register A1 TRDGRA1 R/W – –
FFFFH
Note
F0289H
F028AH Timer RD general register B1 TRDGRB1 R/W – –
FFFFH
Note
F028BH
Note The timer RD SFRs are undefined when FRQSEL4 = 1 in the user option byte (000C2H/020C2H) and TRD0EN = 0
in the PER1 register. If it is necessary to read the initial value, set f
CLK to fIH and TRD0EN = 1 before reading.
