Ricoh Aficio SP C232SF Service Manual

Service Menu
M018/M019 4-4 SM Appendix
Engine Maintenance
Destination
Sets the destination and updates the engine setting.
JPN/ NA (Default)/ EU/ ASIA/ China
2nd Transfer
Front
Adjusts the transfer roller current, based on the
default value.
[-15 to 15 / 0 (Default) / 1 μA/step]
2nd Transfer
Back
Adjusts the transfer roller current, based on the
default value.
[-15 to 15 / 0 (Default) / 1 μA/step]
Fuser
Temperature
Adjusts the temperature of the fusing unit, based
on the default value.
[-30 to 0 / 0 (Default) / 2°C/step]
2nd Transfer
Fuser Temp.
Media Type
Plain Paper (90-105 g/m
2
)/ Plain Paper/ Thick
Paper (1405-110 g/m
2
)/ Thin Paper (60-75 g/
2
)/
Thick Paper (Post Card)/ Envelop/ Cardstock/
Bond paper/ Label Paper/ Prepunched/
Preprinted/ Letterhead/ Color/ Recycled
Horiz. Tray1
Adjusts the horizontal registration for tray 1. If the
machine settings are reset to the factory defaults,
this value does not change.
[-15 to 15 / 0 (Default) / 4 mm/step]
Vert.Tray1
Adjusts the vertical registration for tray 1. If the
machine settings are reset to the factory defaults,
this value does not change.
[-15 to 15 / 0 (Default) / 0.24 mm/step]
Registration
Horiz.Tray2
Adjusts the horizontal registration for tray 2. If the
machine settings are reset to the factory defaults,
this value does not change.
[-15 to 15 / 0 (Default) / 4 mm/step]
