Laser Optics
M018/M019 4-10 SM
Always use two hands when carrying the laser optics housing unit. Be sure not
to drop the laser optics housing unit.
10. Take out the harnesses [F] (
x 1).
11. Pull out the harnesses from the rear side.
12. Remove the laser optics housing unit.
