Technical Bulletin PAGE: 3/3
Model: CH-C1
Date: 14-Jan-14
No.: RD135058
9. Slide the idle rollers of duplex transport rollers [C] and [D] with your fingers toward the
back side of the machine as far as they go.
Caution: Make sure to grip the edge of the rollers, not the surface.
10. Slide the drive rollers of duplex transport rollers [A] and [B] with your fingers toward the
back side of the machine as far as they go.
Caution: Make sure to grip the edge of the rollers, not the surface.
11. Close the duplex unit lower guide plate and push the drawer unit back into the
machine.
12. Set SP5-806-195 (Shift Roller Motor1:Homing) ON and then OFF.
13. Repeat steps 8 through 12 five times and run a test job to confirm SC515-01 does not
occur.
Note: If the SC persists, repeat steps 1 through 13.
