Technical Bulletin PAGE: 6/6
Model: Model CH-C1
Date: 19-Jun-13
No.: RD135026
3. Peel off the used web (M0774288 WEB:POLISH:FUSING).
4. Peel off the seals on both ends of the new web, and then wrap the web around the tool.
5. Attach the metal plate to the tool.
6. Fasten the bottom screw to complete the procedure.
