Technical Bulletin PAGE: 3/7
Model: CH-C1a
Date: 07-Mar-14
No.: RD135104
7. Remove the inner cover [A] (4 screws, M3 x 8).
8. Behind the inner cover at [B] and [C], press the lock tab to the right to release the inner
cover from the frame.
9. Remove the plastic knockouts [D].
10. Remove the rear cover. (2 screws)
11. Remove the punch cover [A]. (1 screw)
