Technical Bulletin PAGE: 12/14
Reissued:15-Oct-13
Model: CH-C1
Date: 17-Sep-13
No.: RD135028b
17. Put back the charge roller unit and PCDU and attach the face plate.
After attaching the face plate, check the status of the locking levers again by looking
through the holes as shown.
[A]: The locking lever is properly fit in the hole in the machine frame.
[B]: The locking lever is not properly fit in the hole in the machine frame.
