Technical Bulletin PAGE: 14/14
Reissued:15-Oct-13
Model: CH-C1
Date: 17-Sep-13
No.: RD135028b
3. Turn the ITB separation lever [A] clockwise until it is vertical.
4. Put back the toner supply unit and secure it with screws. (screw x2 / screw x3)
When attaching the toner supply unit to the machine, make sure the hooks on the toner
supply unit fit in the holes on the slide rails.
5. Put back the ITB cleaning intake fan. (screw x1)
6. Attach the drawer unit cover. (screw x7)
