Ricoh CH-C1 User Manual

Technical Bulletin PAGE: 16/17
Reissued:4-Jul-14
Model: CH-C1
Date: 19-Jun-14
No: RD135136a
29. Attach the modified slide rails by following the removal steps in reverse order.
30. Match the cutouts [A] and [B] with the pins [A] and [B] to mount the unit on the rails. (screw x4)
Left side:
Right side:
A
B
A
B
A
B
