ELECTRICAL COMPONENTS
J001/J003 6-42 SM
6.8.7 CONNECTOR LIST
Control Board
Connector No. Connects To:
CN100 Air Release SOL
Air SN
Waste Ink Tank Full SN
CN101 DRV Board I/F
CN102 Relay Board I/F
CN103 PSU I/F
CN104 Operation Panel I/F
CN105 USB I/F
CN106 --- Not Used ---
CN107 COM Board I/F
DRV Board
Connector No. Connects To:
CN200 Control Board I/F
CN201 Maintenance Motor
CN202 Ink Supply Motor
Cartridge Reset
Maintenance Motor DP
CN203 --- Note Used ---
CN204 Print Head Drive
COM Board
Connector No. Connects To:
CN1 Print Head 1 (Odd) I/F
CN2 Print Head 1 (Even) I/F
CN3 Print Head 2 (Odd) I/F
CN4 Print Head 2 (Even) I/F
CN5 Print Head 3 (Odd) I/F
CN6 Print Head 3 (Even) I/F
CN7 Print Head 4 (Odd) I/F
CN8 Print Head 4 (Even) I/F
CN9 Waste Ink Tank Full Sensor
CN10 Registration Sensor
CN11 Control Board I/F
CN12 Control Board I/F
