J007/J010/J011 38 Call Center Manual
Ink Collection Tank Cover
First, always switch the printer off and disconnect the power cord from the power
source. Then disconnect all other cables (USB, etc.)
1. At the right rear corner, push down tab [1].
2. Disconnect the cover hooks from the printer body and remove the cover [2].
Duplex Unit
First, always switch the printer off and disconnect the power cord from the power
source. Then disconnect all other cables (USB, etc.)
1. Raise the left and right release tabs [1] and [2] to unlock the duplex unit..
2. Pull the Duplex Unit [3] straight out of the printer.
