6.5.6 CONNECTOR LIST
J001/J003 Manual Reference
6.8.7 Connector List
Comment
There are some changes in the arrangement of connectors.
New or changed connectors are shaded light gray in the
tables below.
Control Board
Connector No. Connects To:
CN100 Air Release SOL
Air SN
Waste Ink Tank Full SN
CN101 DRV Board I/F
CN102 Relay Board I/F
CN103 PSU I/F
CN104 Operation Panel I/F
CN105 USB I/F
CN106 --- Not Used ---
CN107 COM Board I/F
DRV Board
Connector No. Connects To:
CN200 Control Board I/F
CN201 Maintenance Motor
CN202 Ink Supply Motor
Cartridge Reset
Maintenance Motor HP
CN203 --- Note Used ---
CN204 Print Head Drive
CN205 Humidity SN
COM Board
Connector No. Connects To:
CN1 Print Head 1 (Odd) I/F
CN2 Print Head 1 (Even) I/F
CN3 Print Head 2 (Odd) I/F
CN4 Print Head 2 (Even) I/F
CN5 Print Head 3 (Odd) I/F
CN6 Print Head 3 (Even) I/F
CN7 Print Head 4 (Odd) I/F
CN8 Print Head 4 (Even) I/F
CN9 Waste Ink Tank Full Sensor
CN10 Registration Sensor
CN11 Control Board I/F
CN12 Control Board I/F
