IMAGE ADJUSTMENT
SM 3-17 J001/J003
Replacement
Adjustment
3.7 IMAGE ADJUSTMENT
You can see the image adjustment features on the “Maintenance” sheet of the
printer driver. These four buttons are used for the adjustments:
• Adjust Paper Feed
• Nozzle Blockage Check
• Adjust Print Head Position
• Registration (Print Start Position)
3.7.1 PREPARING FOR TEST PRINTING
1. Make sure A4 size or LTR size paper is loaded in the printer.
2. Make sure the printer is ready to print.
3.7.2 OPENING THE PRINTER DRIVER
1. On the computer, click the [Start] button.
2. Select “Settings”> “Printers”>. Then right-click the printer icon.
3. Select “Properties” from the pop-up menu to open the printer driver Properties
Window.
To Next Page
