Transport Belt Charge Adjustments
SM 4-45 J007/J010/J011
J007/010/
J011
SP No. Menu Title Meaning
1125 CHG:W1:MIDL:13 Charge Width Setting: Simplex (MID: Mj4: ID1)
1126 CHG:W1:EDGE:14 Charge Width Setting: Simplex (LE/TE: Mj4: ID2)
1127 CHG:W1:MIDL:14 Charge Width Setting: Simplex (MID: Mj4: ID2)
1128 CHG:W1:EDGE:15 Charge Width Setting: Simplex (LE/TE: Mj4: ID3)
1129 CHG:W1:MIDL:15 Charge Width Setting: Simplex (MID: Mj4: ID3)
1130 CHG:W1:EDGE:16 Charge Width Setting: Simplex (LE/TE: Mj4: ID4)
1131 CHG:W1:MIDL:16 Charge Width Setting: Simplex (MID: Mj4: ID4)
1132 CHG:W2:EDGE:1 Charge Width Setting: Duplex (LE/TE: Mj1: ID1)
1133 CHG:W2:MIDL:1 Charge Width Setting: Duplex (MID: Mj1: ID1)
1134 CHG:W2:EDGE:2 Charge Width Setting: Duplex (LE/TE: Mj1: ID2)
1135 CHG:W2:MIDL:2 Charge Width Setting: Duplex (MID: Mj1: ID2)
1136 CHG:W2:EDGE:3 Charge Width Setting: Duplex (LE/TE: Mj1: ID3)
1137 CHG:W2:MIDL:3 Charge Width Setting: Duplex (MID: Mj1: ID3)
1138 CHG:W2:EDGE:4 Charge Width Setting: Duplex (LE/TE: Mj1: ID4)
1139 CHG:W2:MIDL:4 Charge Width Setting: Duplex (MID: Mj1: ID4)
1140 CHG:W2:EDGE:5 Charge Width Setting: Duplex (LE/TE: Mj2: ID1)
1141 CHG:W2:MIDL:5 Charge Width Setting: Duplex (MID: Mj2: ID1)
1142 CHG:W2:EDGE:6 Charge Width Setting: Duplex (LE/TE: Mj2: ID2)
1143 CHG:W2:MIDL:6 Charge Width Setting: Duplex (MID: Mj2: ID2)
1144 CHG:W2:EDGE:7 Charge Width Setting: Duplex (LE/TE: Mj2: ID3)
1145 CHG:W2:MIDL:7 Charge Width Setting: Duplex (MID: Mj2: ID3)
1146 CHG:W2:EDGE:8 Charge Width Setting: Duplex (LE/TE: Mj2: ID4)
1147 CHG:W2:MIDL:8 Charge Width Setting: Duplex (MID: Mj2: ID4)
1148 CHG:W2:EDGE:9
Charge Width Setting: Duplex (LE/TE: Mj3: ID1) (Future
Use)
1149 CHG:W2:MIDL:9
Charge Width Setting: Duplex (MID: Mj3: ID1) (Future
Use)
1150 CHG:W2:EDGE:10
Charge Width Setting: Duplex (LE/TE: Mj3: ID2) (Future
Use)
1151 CHG:W2:MIDL:10
Charge Width Setting: Duplex (MID: Mj3: ID2) (Future
Use)
