SP Tables
SM 5-35 J007/J010/J011
J007/J010
J011
Display Maintenance Log: Total Count
7428 LAST MNT CNT1 Log 1: Previous
7429 LAST MNT CNT2 Log 2: Previous -1
7430 LAST MNT CNT3 Log 3: Previous -2
Use this SP to display the total count for all maintenance executions.
Display Near Full Flag: Right Ink Collection Unit
7431 WASTE NEAR FLG
Use this SP to display the near-full flag of the right ink collection tank.
Display Position of Tank Full Feeler for Each Print Head Tank After Air
Purge
7500 INIT POS:T1 Print Head Tank 1
7501 INIT POS:T2 Print Head Tank 2
7502 INIT POS:T3 Print Head Tank 3
7503 INIT POS:T4 Print Head Tank 4
7504 INIT POS:T5 Print Head Tank 5
7505 INIT POS:T6 Print Head Tank 6
Use this SP to display the detected position of the print head tank full sensor at
air venting/ink filling.
Display Normal Position for Detection of Full Print Head Tank
7506 FULL POS:T1 Print Head Tank 1
7507 FULL POS:T2 Print Head Tank 2
7508 FULL POS:T3 Print Head Tank 3
7509 FULL POS:T4 Print Head Tank 4
7510 FULL POS:T5 Print Head Tank 5
7511 FULL POS:T6 Print Head Tank 6
Use this SP to display the usual position of the print tank full sensor when the ink
tank is filled
Rev. 09/2008
