Important Parts
SM 6-3 J007/J010/J011
J007/J010/
J011
press them down again after reinstalling the duplex unit.
7. Ink collection tank cover
Open and remove the ink collection tank when it needs to be replaced, or before
servicing the printer.
8. NIB cover
Remove this cover to access the network interface board.
