Inserted values higher than MaxValue are corrected automatically by the software.
The minimum Lower Level lLevmin ≥ MinValue
Inserted values lower than MaxValue are corrected automatically by the software
Example:
Max. value 600m3/h 10V of the analog signal
Min. value 150m3/h 0V of the analog signal
The above example allows monitoring the scenario as seen below:
The actual measured value is higher than the defined upper limit.
The system is not in its normal status. The upper limit is exceeded. A message is sent (if thisis activated by
). The message text can be freely configured.
The actual measured value is between the Upper and the Lower Level.
The installation is in normal status. A message shall be sent (if default set) .
