Name
Address:
Q1-Q4
0….7
Q11-Q14
8---15
Q21-Q24
16…23
…..
……
F: digital flag
Name
Address:
F1-F64
0….63
WORD data can be used to set the register “AQ” and “AF”
AQ analog outputs
Name
Address:
AQ1-AQ2
0….1
AQ11-AQ12
2---3
AQ21-AQ22
4…5
…..
……
AF analog flags
Name
Address:
AF1-AF64
0….63
Count
Here is to set how many register you want to set once.
