Rockwell Automation Publication 2080-UM002M-EN-E - April 2022 115
Chapter 6 Micro870 Controller Distributed Network Protocol
5 CHATTER_FILTER Always 0. Not used.
6 STATE Reflects point state of Double-bit Binary Input point. Double-bit LSB.
7 STATE Reflects point state of Double-bit Binary Input point. Double-bit MSB
Object Flags for Binary Output
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is in Executing mode and the configuration file
exists.
1 RESTART Always 0. Not used.
2 COMM_LOST Always 0. Not used.
3 REMOTE_FORCED Always 0. Not used.
4 LOCAL_FORCED Always 0. Not used.
5 Reserved Always 0. Not used.
6 Reserved Always 0. Not used.
7 STATE Reflects point state of Binary Output point.
Object Flags for Counter
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is in Executing mode and the configuration file
exists.
1RESTART
0 when the controller is or was in Non-executing mode.
0 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is in Executing mode and the configuration file
exists.
2 COMM_LOST
3 REMOTE_FORCED
4 LOCAL_FORCED
5 ROLLOVER
6 DISCONTINUITY
7Reserved
Object Flags for Analog Input
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is in Executing mode and the configuration file
exists.
1RESTART
0 when the controller is or was in Non-executing mode.
0 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is in Executing mode and the configuration file
exists.
2 COMM_LOST
3 REMOTE_FORCED
4 LOCAL_FORCED
5OVER_RANGE
6 REFERENCE_ERR
7Reserved
Object Flags for Double Binary Input (Continued)
Bit Offset Name Description
