Rockwell Automation Publication 2080-UM002M-EN-E - April 2022 59
Chapter 5
Communication Connections
Overview This chapter describes how to communicate with your control system and
configure communication settings. The method you use and cabling required
to connect your controller depends on what type of system you are employing.
This chapter also describes how the controller establishes communication with
the appropriate network. Topics include:
The Micro830, Micro850, and Micro870 controllers have the following
embedded communication channels:
• a non-isolated RS-232/RS-485 combo port
• a non-isolated USB programming port
In addition, the Micro850 and Micro870 controllers have an RJ-45 Ethernet
port.
Supported Communication
Protocols
Micro830, Micro850, and Micro870 controllers support communication
through the embedded RS-232/RS-485 serial port as well as any installed serial
port plug-in modules. In addition, Micro850 and Micro870 controllers also
support communication through the embedded Ethernet port, and can be
connected to a local area network for various devices providing 10 Mbps/
100 Mbps transfer rate.
These are the communication protocols supported by Micro830/Micro850/
Micro870 controllers:
• Modbus RTU Master and Slave
• CIP Serial Client/Server (DF1)
• CIP Symbolic Client/Server
•ASCII
•DNP3
(1)
Topic Page
Supported Communication Protocols 59
CIP Communications Pass-thru 64
Use Modems with Micro800 Controllers 65
Configure Serial Port 66
Configure Ethernet Settings 71
Configure CIP Serial Driver 73
OPC Support Using FactoryTalk Linx 73
(1) DNP3 is only supported on 2080-L70E-24QxBN controllers.
