116 Rockwell Automation Publication 2080-UM002M-EN-E - April 2022
Chapter 6 Micro870 Controller Distributed Network Protocol
DNP3 Device Attribute
Object
The Device Attribute object can be used to identify DNP3 Slave devices.
With the controller, some of the variations are written so that you can read or
write your own strings in your application.
The R/W property shows if the object is Read Only, Read, or Write. If the R/W
property is writable, the value which was written by DNP3 master device is
stored to non-volatile memory.
The object group of the Device Attribute is 0. The supported range of the
variation is 209…255.
Object Flags for Analog Output
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is in Executing mode and the configuration file
exists.
1RESTART
0 when the controller is or was in Non-executing mode.
0 when the controller is or was in Executing mode and the configuration file
does not exist.
May be 1 when the controller is in Executing mode and the configuration file
exists.
2 COMM_LOST
3 REMOTE_FORCED
4 LOCAL_FORCED
5Reserved
6Reserved
7Reserved
Object Group 0, Variations for Attribute Set 0
Variation Read/Write
Attribute
Data Type
Max Length in Bytes Description Value
209 Read Only UINT 1
Secure authentication version supported in out
station
5
210 Read Only UINT 1 Number of secure statistic available in out station 18
212 Read Only UINT 1 Number of master-defined Data-Set prototypes 1
213 Read Only UINT 1 Number of outstation-defined Data-Set prototypes 1
214 Read Only UINT 1 Number of master-defined Data-Sets 1
215 Read Only UINT 1 Number of outstation-defined Data-Sets 1
216 Read Only UINT 1 Max number of binary outputs per request 1
217 Read Only UINT 4 Local timing accuracy 100 in microseconds
218 Read Only UINT 4 Duration of timing accuracy 100 in seconds
219 Read Only INT 1 Support for analog output events 1
220 Read Only UINT 4 Max analog output index 0
221 Read Only UINT 4 Number of analog outputs 0
222 Read Only INT 1 Support for binary output events 1
223 Read Only UINT 4 Max binary output index 0
224 Read Only UINT 4 Number of binary outputs 0
225 Read Only INT 1 Support for frozen counter events 1
226 Read Only INT 1 Support for frozen counters 1
227 Read Only INT 1 Support for counter events 1
228 Read Only UINT 4 Max counter index 0
229 Read Only UINT 4 Number of counter points 0
230 Read Only INT 1 Support for frozen analog inputs 1
231 Read Only INT 1 Support for analog input events 1
232 Read Only UINT 4 Maximum analog input index 0
