216 Rockwell Automation Publication 2080-UM002M-EN-E - April 2022
Chapter 10 Controller Security
2. In the Project Organizer, expand Catalog by clicking the + sign.
3. Select the catalog number of your controller.
4. When requested, provide the controller password.
5. Build and save your project.
6. Debug.
Download to a Password-Protected Controller
1. Launch the Connected Components Workbench software.
2. Click Connect.
3. Select the target controller.
4. When requested, provide the controller password.
5. Build and save the project, if needed.
6. Click Download.
7. Click Disconnect.
Transfer Controller Program and Password-Protect Receiving
Controller
In this scenario, the user needs to transfer user application from controller1
(locked) to another Micro800 controller with the same catalog number. The
transfer of the user application is done through the Connected Components
Workbench software by uploading from controller1, then changing the target
controller in the Micro800 project, and then downloading to controller2.
Finally, controller2 will be locked.
1. In the Project Organizer, click the Discover icon.
The Browse Connections dialog appears.
2. Select target controller1.
3. When requested, enter the controller password for controller1.
4. Build and save the project.
5. Click Disconnect.
6. Power down controller1.
7. Swap controller1 hardware with controller2 hardware.
8. Power up controller2.
IMPORTANT
If the controller has a password locked version 10 or later project, you
cannot access the controller using Connected Components Workbench
software version 9 or earlier. If you use Connected Components
Workbench software version 10 or later to download a version 9 or
earlier project, the password in the controller will be automatically
converted to the old algorithm.
IMPORTANT
If the controller has a password locked version 9 or earlier project and
you use Connected Components Workbench software version 10 or later,
to download a version 10 or later project, the password in the controller
will be automatically converted to the new algorithm.
IMPORTANT
If communication is lost during the download, repeat the download and
verify that the controller is password protected.
