Rockwell Automation Publication 2080-UM002M-EN-E - April 2022 75
Chapter 6
Micro870 Controller Distributed Network
Protocol
Overview This chapter describes how to configure the DNP3 communication settings.
Topics include:
Channel Configuration for
DNP3 Slave
The default communication protocol for the serial ports is DF1 Full-Duplex. To
communicate with Distributed Network Protocol (DNP3), the channel must be
configured for DNP3 Slave.
The default communication protocol for the Ethernet channel in the controller
is EtherNet/IP. To communicate with DNP3 over IP protocol, select DNP3 over
IP Enable in the Ethernet configuration page.
To program the controller, use Connected Components Workbench software
version 20.01.00 or later.
Topic Page
Channel Configuration for DNP3 Slave 75
DNP3 Slave Application Layer 100
DNP3 Objects and Controller Variables 105
DNP3 Device Attribute Object 116
Event Reporting 117
Collision Avoidance 122
Time Synchronization 123
Diagnostics 124
Function Codes 126
Implementation Table 127
IMPORTANT
The DNP3 protocol is only supported in the following Micro870
controllers.
• 2080-L70E-24QBBN
• 2080-L70E-24QWBN
