20 Rockwell Automation Publication 2080-UM002M-EN-E - April 2022
Chapter 1 Hardware Overview
18 Network Status 23 Serial communications status
19 Power status 24 Output status
20 Run status
(1) For detailed descriptions of the different status LED indicators, see Troubleshooting on page 303.
You can order replacement terminal blocks, catalog number 2080-RPL24RTB,
separately.
Status Indicator Description
(1)
(Continued)
Description Description
Table 1 - Micro830 Controllers – Number and Types of Inputs/Outputs
Catalog Number
Inputs Outputs
PTO Support HSC Support
110V AC 24V DC/V AC Relay 24V Sink 24V Source
2080-LC30-10QWB – 6 4 – – – 2
2080-LC30-10QVB – 6 – 4 – 1 2
2080-LC30-16AWB 10 – 6 – – – –
2080-LC30-16QWB – 10 6 – – – 2
2080-LC30-16QVB – 10 – 6 – 1 2
2080-LC30-24QWB – 14 10 – – – 4
2080-LC30-24QVB – 14 – 10 – 2 4
2080-LC30-24QBB – 14 – – 10 2 4
2080-LC30-48AWB 28 – 20 – – – –
2080-LC30-48QWB – 28 20 – – – 6
2080-LC30-48QVB – 28 – 20 – 3 6
2080-LC30-48QBB – 28 – – 20 3 6
Table 2 - Micro850 Controllers – Number and Types of Inputs/Outputs
Catalog Number
Inputs Outputs
PTO Support HSC Support
120V AC 24V DC/V AC Relay 24V Sink 24V Source
2080-LC50-24AWB 14 – 10 – – – –
2080-L50E-24AWB 14 – 10 – – – –
2080-LC50-24QWB – 14 10 – – – 4
2080-L50E-24QWB – 14 10 – – – 4
2080-LC50-24QVB – 14 – 10 – 2 4
2080-L50E-24QVB – 14 – 10 – 2 4
2080-LC50-24QBB – 14 – – 10 2 4
2080-L50E-24QBB – 14 – – 10 2 4
2080-LC50-48AWB 28 – 20 – – – –
2080-L50E-48AWB 28 – 20 – – – –
2080-LC50-48QWB – 28 20 – – – 6
2080-L50E-48QWB – 28 20 – – – 6
2080-LC50-48QWBK – 28 20 – – – 6
2080-L50E-48QWBK – 28 20 – – – 6
