Chapter 11 Using microSD Cards
Build and Download
After configuring Recipe, build the program and download to the controller.
Execute RCP Function Block
Execute the RCP function block. Notice the Status output go from 0 (Idle) to
1 (Enable), and 2 (Succeed).
Upload Recipe Files
You can retrieve recipe files from the microSD card using a card reader or by
uploading the recipe files through the Connected Components Workbench
software.
1. To use the Upload feature, go to the Properties section of your project in
the Connected Components Workbench software.
2. Select Recipe. Click Manage and then choose Upload.
Through Manage, you can also choose to Download and Delete recipe
files.
3. From the Upload window that appears, select the batch of recipe files
that you would like to upload.
