4-12
Programming
Advanced Setup
While the Basic Setup group allows the user to get started with a
minimum number of parameters to modify, the Advanced Setup
group allows full access to the SMC Dialog Plus controller’s powerful
parameter set. Following is a listing of the additional setup
parameters provided.
Note: All of the Basic Setup parameters are available in the
Advanced Setup group. The parameters shown below are in
addition to the parameters in Basic Setup.
①
The Dual Ramp feature is available only with the standard controller.
②
The delay time must be set to a value greater than zero when Undervoltage, Overvoltage, and
Unbalance are enabled.
③
For Jam and Underload detection to function, the Motor FLC must be programmed in the Calibration
group. See Chapter 5 for instructions.
④
To enable Rebalance, the Converter Rating parameter in the Calibrate programming group must be
set for 20, 180, or 630.
Parameter Option
Dual Ramp
①
Allows the user the option to choose between two
Soft Start profiles.
Off, On
Ramp Time #2
Determines the soft start time for the second ramp
of the Dual Ramp feature.
0 to 30 seconds
Initial Torque #2
Provides the initial torque setting for the second
ramp of the Dual Ramp feature.
0 to 90% locked rotor torque
Undervoltage Level
Determines the trip level as a percentage of line
voltage.
0 to 99% (0 is the Off setting)
Undervoltage Delay
②
Provides a delay period prior to a trip occurrence.
0 to 99 seconds
Overvoltage Leve
l
Determines the trip level as a percentage of line
voltage.
0 to 199% (0 is the Off setting)
Overvoltage Delay
②
Provides a delay period prior to a trip occurrence.
0 to 99 seconds
Jam Level
③
Determines the trip level as a percentage of the
motor’s full load current.
0 to 999% (0 is the Off setting)
Jam Delay
Provides a delay period prior to a trip occurrence.
0.0 to 10.0 seconds
Unbalance Level
Allows the user to set the voltage unbalance trip
level.
0 to 25% (0 is the Off setting)
Unbalance Delay
②
Provides a delay period prior to a trip occurrence.
0 to 99 seconds
Rebalance
④
Allows the user access to enable the Rebalance
feature. See page 1-5 for a description.
Off, On
Underload Level
②
Determines the trip level as a percentage of the
motor’s full load current.
0 to 99% (0 is the Off setting)
Underload Delay
Provides a delay period prior to a trip occurrence.
0 to 99 seconds
