Rockwell Automation SMC Dialog Plus User Manual

3-12
Wiring
Standard Controller
Wiring Diagrams (cont.)
Figure 3.16 Typical Wiring Diagram for Isolation Applications
①
Customer supplied.
②
Refer to the controller nameplate to verify the rating of the control power input voltage.
Stop
➀
Start
➀
3-Phase
Input Power
Branch
Protection
➀
Fast-acting
SCR Fuses
(optional)
➀
Isolation
Contactor
(IC)
➀
M
➀
IC
➀
➀
➀
➀
➁
L1/1
L2/3
L3/5
T1/2
T2/4
T3/6
11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30
Internal
Auxiliary
Contacts
Auxiliary contacts
set for Normal
SMC Dialog Plus
Controller
SMC Dialog Plus
Control Terminals
