Rockwell Automation SMC Dialog Plus User Manual

3-16
Wiring
Standard Controller
Wiring Diagrams (cont.)
Figure 3.20 Typical Wiring Diagram for Single Speed Reversing Applications
①
Customer supplied.
②
Refer to the controller nameplate to verify the rating of the control power input rating.
Notes: (1) Minimum transition time for reversing direction is 1/2 second.
(2) Phase Reversal protection
must
be disabled in reversing applications.
Stop
➀
OFF
➀
FOR REV
F
F
F
R
R
R
➁
3-Phase
Input Power
Branch
Protection
➀
Reversing Contactors
➀
Fast-acting
SCR Fuses
(optional)
➀
Bulletin 825
Coverter
Module
(optional)
➀
M
➀
➀
➀
➀
F
R
L1/1
L2/3
L3/5
T1/2
T2/4
T3/6
➀
➀
➀
➀
➀
➀
11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30
Internal
Auxiliary
Contacts
SMC Dialog Plus
Controller
SMC Dialog Plus
Control Terminals
