Rockwell Automation SMC Dialog Plus User Manual

Product Overview
1-7
Figure 1.6 Overload Trip Curves
Figure 1.7 Restart Trip Curves after Auto Reset
Approximate trip time for 3-phase balanced
condition from cold start.
Approximate trip time for 3-phase balanced
condition from cold start.
Class 10 Class 15 Class 20 Class 30
Multiples of FLC Multiples of FLC Multiples of FLC Multiples of FLC
Approximate Trip Time (seconds) Approximate Trip Time (seconds) Approximate Trip Time (seconds) Approximate Trip Time (seconds)
1.0
10.0
100.0
1000.0
10000.0
1 10 2 3 9 8 7 6 5 4
0.1
1.0
10.0
100.0
1000.0
1 10 2 3 9 8 7 6 5 4
1.0
10.0
100.0
1000.0
10000.0
1 10 2 3 9 8 7 6 5 4
1.0
10.0
100.0
1000.0
10000.0
1 10 2 3 9 8 7 6 5 4
1000%100%
0
1
10
100
1000
100000
Percent Full Load Current Setting
Seconds
Class 10
Class 15
Class 20
Class 30
Auto Reset Times:
Class 10 = 90s
Class 15 = 135s
Class 20 = 180s
Class 30 = 270s
