Example:
TRIGger:I2C:DATA '11111111000000001111'
TRIGger:I2C:DATA?
<-- 11111111000000001111XXXX
TRIGger:I2C:DCONdition <Relation>
Defines how the specified data pattern is compared with the acquired signal. The
instrument triggers if the acquired data is equal or unequal to the pattern.
Parameters:
<Relation> EQUal | NEQual
*RST: EQUal
TRIGger:I2C:DPOSition
<ByteOffset>
Sets the number of bytes before the first byte of the data pattern. These bytes are
ignored.
Parameters:
<ByteOffset> Range: 0 to 4095
Increment: 1
*RST: 0
15.11.2.3 I2C Decode Results
The frame suffix <m> selects the frame index for which the result is queried.
The byte suffix <n> selects the byte index for which the result is queried.
BUS:I2C:FCOunt?..........................................................................................................431
BUS:I2C:FRAMe<m>:AACCess?.....................................................................................431
BUS:I2C:FRAMe<m>:ACCess?.......................................................................................431
BUS:I2C:FRAMe<m>:ACOMplete?..................................................................................431
BUS:I2C:FRAMe<m>:ADBStart?..................................................................................... 432
BUS:I2C:FRAMe<m>:ADDRess?.................................................................................... 432
BUS:I2C:FRAMe<m>:ADEVice?......................................................................................432
BUS:I2C:FRAMe<m>:AMODe?....................................................................................... 432
BUS:I2C:FRAMe<m>:ASTart?.........................................................................................433
BUS:I2C:FRAMe<m>:BCOunt?....................................................................................... 433
BUS:I2C:FRAMe<m>:BYTE<n>:ACCess?........................................................................433
BUS:I2C:FRAMe<m>:BYTE<n>:ACKStart?...................................................................... 433
BUS:I2C:FRAMe<m>:BYTE<n>:COMPlete?.....................................................................434
BUS:I2C:FRAMe<m>:BYTE<n>:STARt?.......................................................................... 434
BUS:I2C:FRAMe<m>:BYTE<n>:VALue?.......................................................................... 434
BUS:I2C:FRAMe<m>:DATA?.......................................................................................... 435
BUS:I2C:FRAMe<m>:RWBStart?.................................................................................... 435
BUS:I2C:FRAMe<m>:STARt?......................................................................................... 435
BUS:I2C:FRAMe<m>:STATus?....................................................................................... 435
BUS:I2C:FRAMe<m>:STOP?..........................................................................................436
