Rohde ST 310 - Page 61

59 / 293 - EN -
No. Display Indicator Meaning Description
3
20
Firing chamber
temperature
First, the current firing chamber temperature is
displayed.
4
Go back some steps
• Press the h key to go back one step to the
previous value.
• To select a new program number from the
program memory, press the h key to go
back to “Firing chamber temperature (No. 3)”
and then press the X key to return to the
program memory.
• To further customise the programming,
proceed to step #5.
5
20
Continue programming
Press the g key to select the next program
step.
6
00.00
Enter program delay t
0
• Press the d and f keys to select the
program delay.
• For technical reasons, there is a point
between the hours and minutes in the
display and not a colon, as is usually the
case with times.
• If you do not enter a program delay or if the
display shows “00.00”, the firing program
starts immediately after you have pressed
the j key.
• You can enter program delays up to “99.59
(h.min)”.
• Press the g key to select the next program
step.
7
150
1. Enter heating rate
Rmp
1
• Press the d and f keys to select the ramp
rate.
• The ramp rate appears on the main display
as:
“1 – 999” (°C/h), FULL (maximum ramp rate)
or END (program end).
• Press the g key to select the next program
step.
8
600
1. Enter switch point
Tmp
1
• Press the d and f keys to select the
temperature.
• The temperature appears on the main display
as: “0 – 1400” (°C). This depends on the kiln
model and its maximum temperature.
• If the entered temperature Tmp
1
is lower than
the current “Firing chamber temperature (No.
3)”, Rmp
1
and Tmp
1
are automatically
skipped in the firing program when the
program starts, and the controller starts at
Rmp
2
.
• Press the g key to select the next program
step.
