Panel Descriptions
STRUCTURE
Here you can turn each sound-producing element (section) on or off.
[1], [2], [3]
Switches the structure type (the way in which the sections are
connected).
[OSC1], [OSC2], [MOD], [COSM1], [COSM2],
[TVA]
These buttons switch the corresponding section on/off.
Only the buttons of the structure type selected by [1], [2], or [3] are
active.
EFFECTS
Here you can switch the onboard effects (multi-effects, chorus,
reverb) on/off. When an effect is on, the indicator for its button will
light.
[MFX]
Switches multi-effects on and off.
[CHORUS]
Switches chorus on and off.
[REVERB]
Switches reverb on and off.
OSC1, OSC2
Here you can adjust the oscillator section.
These knobs are active if the oscillator is on (indicator lit). The result
of adjusting these knob will depend on the oscillator type that is
selected.
[PITCH]
This modifies the pitch.
[TIME]/[PW]
TIME:
This modifies the time.
PW:
This modifies the pulse width.
[FORMANT]/[FAT]
FORMANT:
This modifies the formant.
FAT:
Adjusts the fatness of the sound when using an analog
oscillator.
[LFO DP1], [LFO DP2], [LFO DP3]
These knobs adjust the depth of the LFO that is applied to the
parameters of the knobs located above each knob.
[LFO RATE]
This modifies the LFO rate.
[LEVEL]
This modifies the volume.
COSM1, COSM2
Here you can adjust the COSM sections.
These knobs are active when COSM is on (indicator lit). The result of
adjusting these knobs will depend on the COSM type that is selected.
[WIDTH]/[CUTOFF]/[P1]
WIDTH:
Adjusts the width when SBF (Side Band Filter) is selected.
CUTOFF:
Adjusts the cutoff frequency when TVF is selected.
P1:
Adjusts the parameter specified for the type when other types
are selected.
[DETUNE]/[RESO]/[P2]
DETUNE:
Adjusts the detune when SBF (Side Band Filter) is
selected.
RESO:
Adjusts the resonance when TVF is selected.
P2:
Adjusts the parameter specified for the type when other types
are selected.
TVA
Here you can adjust the TVA section.
These sliders are active when the TVA is on (indicator lit).
[A]
This modifies the Attack Time.
[D]
This modifies the Decay Time.
[S]
This modifies the Sustain Level.
[R]
This modifies the Release Time.
You can also use these sliders to make envelope settings in the
envelope setting screens of other sections.
Pitch Bend/Modulation Lever
This allows you to control pitch bend or apply vibrato.
→
(p. 36)
