184
Effects List
35: Bass Multi
Bass Multi provides Comp/Limiter, Overdrive or Distortion, 3-band
equalizer, and Chorus or Flanger effects connected in series. This
algorithm is a multi-effects for bass.
fig.MFX-35
Mod Mode
(Chorus /
Flanger)
CHORUS,
FLANGER
Selects whether to use chorus or
flanger.
Mod Rate 0.05–10.0 Hz,
note
Adjusts the speed of modulation
for the chorus or flanger.
Mod Depth 0–127 Adjusts the depth of modulation
for the chorus or flanger.
Mod Phase 0–180 deg Sets how the chorus or flanger
sound is spread.
Mod Pre Delay 0–50.0 ms Adjusts the delay time from the
direct sound until the chorus or
flanger sound is heard.
Mod Feedback -98– +98% Adjusts the proportion of the ef-
fect sound that is fed back into
the effect. Negative (-) settings
will invert the phase.
Mod XoverLPF 500–15000 Hz,
THRU
Adjusts the cutoff frequency of
the low pass filter. (THRU: no
filter is used)
Mod XoverHPF THRU, 50–800
Hz
Adjusts the cutoff frequency of
the high pass filter. (THRU: no
filter is used)
Mod Level 0–127 Volume of the chorus or flanger
sound.
Delay Time 0–1300 ms, note Adjusts the delay time from the
direct sound until the delay
sound is heard.
Delay Feedback -98– +98% Adjusts the proportion of the de-
lay sound that is fed back into
the effect. Negative (-) settings
will invert the phase.
Hi Damp Freq 500–15000 Hz,
THRU
Adjusts the frequency above
which sound fed back to the ef-
fect will be cut.
High Damp, by attenuating the
higher frequencies first, makes
the delay sound more natural.
Delay Level 0–127 Volume of the delay sound.
Parameter
Value Description
Comp Sw
OFF, ON Turns the comp/limiter on/off.
Comp Thresh-
old #1
-60–0 dB Sets the volume level at which
the compression begins.
Comp Attack 0–127 Sets the time after the sound vol-
ume is crossed the compressor
threshold until compression be-
gins.
Comp Release 0–127 Specifies the time from when the
volume drops below the com-
pressor threshold until com-
pression is no longer applied.
Comp Ratio 1.5:1, 2:1, 4:1,
100:1
Sets the “source sound:output
sound” compression ratio.
Parameter
Value Description
3-Band
EQ
Chorus/
Flanger
Overdrive/
Distortion
L
R
Comp/
Limiter
Comp Gain
-60– +12 dB Adjusts the output gain.
Distortion Sw OFF, ON Selects whether to use overdrive
or distortion.
Drive Mode OD, DS Selects whether to use overdrive
(OD) or distortion (DS).
Drive 0–127 Degree of distortion
Amp Sim Sw OFF, ON Turns the amp simulator on/off.
Amp Type SMALL,
BUILT-IN, 2-
STACK, 3-
STACK
Type of guitar amp
SMALL: small amp
BUILT-IN: single-unit type amp
2-STACK: large double stack
amp
3-STACK: large triple stack amp
Distortion Level 0–127 Volume of the overdrive or dis-
tortion sound.
EQ Low Freq 50–4000 Hz Frequency of the low range
EQ Low Gain -15– +15 dB Gain of the low range
EQ Mid Freq 50–20000 Hz Frequency of the middle range
EQ Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0
Gain of the middle range
Set a higher value for Q to nar-
row the range to be affected.
EQ Mid Gain -15– +15 dB Gain of the middle range
EQ Hi Freq 2000–20000 Hz Frequency of the high range
EQ Hi Gain -15– +15 dB Gain of the high range
Mod Mode
(Chorus /
Flanger)
CHORUS,
FLANGER
Selects whether to use chorus or
flanger.
Mod Rate 0.05–10.0 Hz,
note
Adjusts the speed of modulation
for the chorus or flanger.
Mod Depth 0–127 Adjusts the depth of modulation
for the chorus or flanger.
Mod Phase 0–180 deg Sets how the chorus or flanger
sound is spread.
Mod Pre Delay 0–50.0 ms Adjusts the delay time from the
direct sound until the chorus or
flanger sound is heard.
Mod Feedback -98– +98% Adjusts the proportion of the ef-
fect sound that is fed back into
the effect. Negative (-) settings
will invert the phase.
Mod XoverLPF 500–15000 Hz,
THRU
Adjusts the cutoff frequency of
the low pass filter. (THRU: no
filter is used)
Mod XoverHPF THRU, 50–800
Hz
Adjusts the cutoff frequency of
the high pass filter. (THRU: no
filter is used)
Mod Level 0–127 Volume of the chorus or flanger
sound.
Parameter
Value Description
Reference_e.book 184 ページ ２００５年３月１０日 木曜日 午後５時６分
