Rondo Rondostar 5000 Basic - Maintenance

Table of contents
Edition BE210202
03.2022
Rondostar 5000
Operating manual
13
6 Cleaning 109
6.1 Cleaning 109
6.1.1 Care 111
6.1.1.1 Machine body and substructure 112
6.1.1.2 Safety guards 112
6.1.1.3 Light barrier / sensor wiper 112
6.1.1.4 Scrapers / Rollers 113
6.1.1.5 Conveyor belts: Top 114
6.1.1.6 Conveyor belts: underside / machine table / drive roller / idle roller 114
6.1.1.7 Table supports 115
6.1.1.8 Flour catch sheets 115
6.1.1.9 Dough catch pans 115
6.1.1.10 Touch screen 115
6.1.1.11 Automatic flour duster
[variant SSH670**.*][standard SSH672***.*, SSH673***.*] 115
6.1.1.12 Automatic reeling device [SSH67*7H*.*] 117
6.1.1.13 Cutting rollers [SSH67***C.*] 117
7 Maintenance 118
7.1 General information for machine maintenance 118
7.2 Software updates 120
7.3 Maintenance list 121
7.4 Replacement kit 122
7.4.1 Checking and replacing the sensor wiper 123
7.4.2 Lubricating the sensor wiper 123
7.4.3 Check and replace gas spring: Safety guards 124
7.4.4 Checking and replacing the gas springs: rigid substructure [SSH673***.*] 125
7.4.5 Checking the safety guards trigger point 126
7.4.6 Replacing the scrapers 126
7.4.6.1 Removing the scrapers 126
7.4.6.2 Replacing the scraper blade 127
7.4.6.3 Mounting the scraper 128
7.4.7 Conveyor belt 128
7.4.7.1 Checking for wear 128
7.4.8 Automatic reeling device: Check seal rings
[SSH67*7H*.*] 128
7.4.9 Automatic flour duster: Adjusting the brush
[variant SSH670**.*][standard SSH672***.*, SSH673***.*] 129
7.4.10 Cutomat: Replacing the guideway [SSH67***C.*] 129
