Roxell FLEX-AUGER FA 75 - Page 106

ROXELL - 031 - 0516
FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-8
FLEX-AUGER
125 LC 125 HC
MAX
(M)
MAX
See III-15 See III-15
RPM - 50Hz 290 390
RPM - 60Hz 348 348
**KG/H (50Hz) 5400 10000
**KG/H (60Hz) 6500 12000
KG/M 5,4 5,4
NOVICOR/STEEL/DENSICOR
NOVICOR/STEEL/DENSICOR :
See page I-70
(mm)
3105 3105
(mm)
3000 3000
Mm
127 127
Mm
117 (NOVICOR/DENSICOR)
123 (STEEL)
117 (NOVICOR/DENSICOR)
123 (STEEL)
Mm
137 (NOVICOR/DENSICOR) 137 (NOVICOR/DENSICOR)
Mm
127 (NOVICOR) 127 (NOVICOR/DENSICOR)
Mm
5 (NOVICOR)
2 (STEEL)
5 (NOVICOR/DENSICOR)
2 (STEEL)
R (mm)
1587 (HARD. STEEL) 2200 (HARD. STEEL)
R (mm)
1700 (NOVICOR) 2200 (DENSICOR)
Mm
1485 (NOVICOR) 1979 (DENSICOR)
Mm
1179 (HARD.STEEL) 1732 (HARD. STEEL)
Mm
5 (NOVICOR) 5 (DENSICOR)
Mm
3 (HARD. STEEL) 3 (HARD. STEEL)
A
B
Mm
Plastic
NOVICOR/DENSICOR
A = 127
B = 117
DENSICOR
A=127
B=117
Mm
A
B
Hard. steel
HARD. STEEL
A =126
B = 120
HARD. STEEL
A=126
B=120
MAX Ø
mm
9 9
Mm
D=
d=
94,60
65,60
94,60
65,60
Pitch Mm
66 85
**For commercial mash, crumble or pellets (dia 3 mm) with a specific weight of 0,65 kg/dm
3
.
