FLEX-AUGER - COMPONENTS

II-17

EXTENSION BOOT FA 75 - 03103884

Key Nam e Part Nr. Qt.

1 CONTROL UNIT FA75 WITHOUT DROP 13109004 1

1.1 HOUSING - CONTROL UNIT Ø75 13109038 1

1.2 WINDOW 13000500 1

1.3 THREAD FORMING SCREW 4X12-A2 12502043 1

1.4 REINFORCEMENT PLATE Ø56-75-90-MOTOR 13109046 1

1.5 SWITCH PLATE WITH PRESS SCREW 13109533 1

1.6 ADHESIVE TAPE 19X0.23-2SIDE 30800726 2

1.7 MINIMUM SWITCH SHIELD 10203115 1

1.8 SWITCH CONNECTION STRIP 13105259 1

1.9 PARCKER SCREW 8X1/2" 20100525 2

1.10 PARCKER SCREW 4.2X16 - DIN 7981 20102331 2

1.11 HANDY BOX IPW AX4-IP55 15009814 1

1.12 NUT M4 20100681 2

1.13 DRIVER WELDMENT 13105200 1

1.14 HARDWARE KIT CU FA 75 13109558 1

1.14.1 ANCHOR CLAMP 13104575 1

1.14.2 SOCKET CAP SCREW M8X10 - DIN 912 20102778 1

1.14.3 SOCKET CAP SCREW M8X50 - DIN 912 20102786 1

1.14.4 LOCKNUT M8 - DIN 985 20100418 1

1.14.5 BOLT M8X20 - DIN 933-8.8 20200150 4

1.15 WASHER 5.3X10X1 - DIN 125 - A2 20102315 2

1.16 CLAMP STROKE 27 20 6E/3 10103109 1

1.17 TUBE CLAMP ASSEMBLY Ø86MM 03103306 1

1.18 SAFETY SWITCH ASS'Y 13104567 1

2 BOOT ASS'Y FA75 FOR EXT.BOOT 13109053 1

2.1 INTAKE BOOT & CLOSING PLATE 13109590 1

2.1.1 BOOT BODY WELDMENT FA 75 13108030 1

2.1.2 GASKET 15X2 30800874 1

2.1.3 CLOSING PLATE 13107776 1

2.1.4 FIBER RING 20104287 1

2.1.5 NUT M10 - DIN 934 20100277 1

2.1.6 CLOSING PROFILE 13107768 1

2.1.7 CLOSING BOLT - BRASS SMAL 13108154 1

2.1.8 DECAL - HANDS WARNING 13106596 1

2.1.9 ROXELL DECAL - 160X40 10101129 1

2.1.10 E-RING Ø5-DIN 6799-A2 S.S 20102018 1

2.1.11 HARDWARE KIT EXTENSION BOOT 13000526 1

2.1.11.1 BOLT M8X20 - DIN 933-8.8 20200150 4

2.1.11.2 NUT M8 DIN 934 - SP 20200119 4

2.1.11.3 SEAL CAP M8 16103699 4

2.1.11.4 KNURLED KNOB 13107842 1

2.2 ANCHOR & BEARING ASS'Y FA75 13109699 1

2.2.1 BEARING HOLDER CAP DOWN - Ø75 13109632 1

2.2.2 BEARING 17X35X10 - 6003 LLU 13201066 1

2.2.3 ANCHOR TUBE WELDMENT Ø36 13109749 1

2.2.4 SEEGER RING Ø17X1 20101333 1

2.2.5 HOSE CLAMP ASSEMBLY Ø70-90 03100658 1

2.2.6 BEARING HOLDER CAP UP - Ø75 13109624 1

2.2.7 BOLT M6X12 - DIN 933-8.8 20100160 2

2.2.8 NUT M6 - DIN 934 20100210 2

4 EXTENSION PLATE Ø160 GALVANISED 13109525 1

5 HW KIT FOR FA EXTENSION 360° 13000518 1

5.1 LOCKNUT M6-DIN 985-A2 20101960 4

5.2 BUT.HEAD CAP SCREW WITH FLANGE M6X16-A2 20109146 4

6 DROP Ø160 FOR EXTENSION BOOT 13000492 1
