ROXELL - 031 - 0516
FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-25
SUSPENSION IN A HOUSE WITH SEPARATED PENS
Provide a straight line suspension through the sep-
aration walls.
Use a hole saw to make holes in
the walls.
Put the tube exactly in the center of the hole to
avoid wear by friction with the wall.
FIGURE 34.
Seal & seal ring
PAY ATTENTION TO THE DIFFERENCE IN LEVELS WHEN USING AN EXTENSION BOOT : LAST
PART 23CM LOWER ! SEE FIG. 38. PAGE III-28.
