Roxell FLEX-AUGER FA 75 - POWER UNIT

ROXELL - 031 - 0516
FLEX-AUGER - COMPONENTS
II-7
3 2
4
1
POWER UNIT
Nam e Part Nr.
SERVICE PARTS
On Demand
FAN COVER On Demand
CONNECTION BOX On Demand
CAPACITOR 1-PHASE MOTOR On Demand
CABLE RING On Demand
Key Name Part Nr. Qt.
POWER UNIT
0..(See table)
1
1GEARBOX
1..(See table)
1
2 MOTOR
1..(See table)
1
3 BOLT M8X30-DIN 933-8.8
20100244
4
4 NUT M8 - DIN 934
20200028
4
System FA-55 FA-75 FA-75/90 FA-90 FA-90 FA-90 HD FA-90 FA-125 FA-125 FA-125
Gearbox With Key
10106441 13105176 13106505 13702923
Gearbox With F-Coupling steel
13204132 13203633 13203633 13203641 13702939 13701636
Gearbox With F-Coupling alu
10111821 13109820 13109828 13204148 13204156 13204164 13702972 13702980
Type Elastic Coupling Set
(CS 71-80-90)
CS71
13204180
CS71
13204180
CS71
13204180
CS71
13204180
CS80
13204196
CS90
13204204
CS90
13204204
CS71
13204180
CS80
13204196
CS90
13204204
Motor Shaft Ø14 Ø14 Ø14 Ø14 Ø19 Ø24 Ø24 Ø14 Ø19 Ø24
Ratio
3.867 7.875 3.867 9.524 2.944 2.944 2.55 12.844 4.75
3.6
Output speed
350 175 350 150 450 450 550 100 290
390
Construction size
71 71 71 71 80 90 90 71 80
90
Motor speed 50Hz(RPM)
1500 1500 1500 1500 1500 1500 1500 1500 1500
1500
Motor speed 60Hz(RPM)
1800 1800 1800 1800 1800 1800 1800 1800 1800
1800
Feed capacity kg
520 600 1.300/2.400 1200 3.100 3.100 3.900 1800 5.400
10.000
Max. Run Time
2 H/day 2 H/day 2 H/day 4 H/day 2 H/day 2 H/day 2 H/day 4 H/day 2/4 H/day
2/4 H/day
3x230/400V 50Hz IE1 00107092 03104262 03104310 03202710 03202734 03202798 03202862 03700869 03700885 03701020
Motor IE1
10106482
(0,37kW)
10106482
(0,37kW)
13106687
(0,74kW)
10106482
(0,37kW)
13203385
(1,1kW)
14800742
(1,5kW)
14800742
(1,5kW)
11901196
(0,55kW)
13203385
(1,1kW)
14800742
(1,5kW)
3x230/400V 50Hz IE2 03202742 03202806 03202870 03700893 03701028
Motor IE2
13204212
(1,1kW IE2)
14802946
(1,5kW IE2)
14802946
(1,5kW IE2)
13204212
(1,1kW IE2)
14802946
(1,5kW IE2)
3x200/346V 50Hz 00107100 03104270 03104318 03202926 03202750 03202814 03202878 03700950 03700901 03701036
Motor
10104487
(0,37kW)
10104487
(0,37kW)
13106158
(0,75kW)
10104487
(0,37kW)
11024247
(1,1kW)
14801443
(1,5kW)
14801443
(1,5kW)
11901436
(0,55kW)
11024247
(1,1kW)
14801443
(1,5kW)
1x230V 50Hz 00107108 03104278 03104326 03202934 03202758 03202822 03202886 03700958 03700909 03701044
Motor
10106656
(0,37kW)
10106656
(0,37kW)
13106661
(0,75kW)
10106656
(0,37kW)
13203351
(1,3kW)
14800841
(1,5kW)
14800841
(1,5kW)
13203351
(1,3kW)
14800841
(1,5kW)
3x220-230/380-400V 60Hz 00107116 03104286 03104334 03202942 03202766 03202830 03202894 03700966 03700918 03701052
Motor
19910249
(0,45kW)
19910249
(0,45kW)
13106216
(0,9kW)
19910249
(0,45kW)
19916030
(1,3kW)
14801450
(1,8kW)
14801450
(1,8kW)
11901444
(0,66kW)
19916030
(1,32kW)
14801450
(1,8kW)
3x200/346V 60Hz 00107124 03104294 03104342 03202950 03202774 03202838 03202902 03700972 03700926 03701060
Motor
13105234
(0,45kW)
13105234
(0,45kW)
13106166
(0,9kW)
13105234
(0,45kW)
13203369
(1,3kW)
14801476
(1,8kW)
14801476
(1,8kW)
13203369
(1,32kW)
14801476
(1,8kW)
3x254/440V 60Hz 00107132 03104298 03104350 03202958 03202782 03202846 03202910 03700980 03700934 03701068
Motor
19913078
(0,45kW)
19913078
(0,45kW)
13106240
(0,9kW)
19913078
(0,45kW)
13203377
(1,3kW)
14801468
(1,8kW)
14801468
(1,8kW)
13203377
(1,32kW)
14801468
(1,8kW)
1x220V 60Hz 00107140 03104302 03104358 03202966 03202790 03202854 03202918 03700988 03700942 03701076
Motor
10110187
(0,55kW)
10110187
(0,55kW)
13108618
(0,9kW)
10110187
(0,55kW)
13203419
(1,3kW)
14802227
(1,8kW)
14802227
(1,8kW)
13203419
(1,32kW)
14802227
(1,8kW)
