Roxell FLEX-AUGER FA 75 - Extension Boot for Overhead Fa90- 03202678

ROXELL - 031 - 0516
FLEX-AUGER - COMPONENTS
II-71
EXTENSION BOOT FOR OVERHEAD FA90- 03202678EXTENSION BOOT FOR OVERHEAD FA90- 03202678
Key Nam e Part Nr . Qt.
1 HOUSING + WINDOW ASS'Y 13000831 1
2 TUBE CLAMP ASSEMBLY Ø100MM 03202561 2
3 WINDOW 13000500 1
5 EXTENSION PLATE Ø160 GALVANISED 13109525 1
6 BOOT ASS'Y FA90 FOR EXT.BOOT 13203831 1
6.1 INTAKE BOOT & CLOSING PLATE FA90 13204003 1
6.1.1 BOOT BODY WELDMENT FA 90 13202965 1
6.1.2 GASKET 15X2 30800874 1
6.1.3 CLOSING PLATE 13107776 1
6.1.4 FIBER RING 20104287 1
6.1.5 NUT M10 - DIN 934 20100277 1
6.1.6 CLOSING PROFILE 13107768 1
6.1.7 CLOSING BOLT - BRASS SMAL 13108154 1
6.1.8 DECAL - HANDS WARNING 13106596 1
6.1.9 ROXELL DECAL - 160X40 10101129 1
6.1.10 E-RING Ø5-DIN 6799-A2 S.S 20102018 1
6.1.11 HARDWARE KIT EXTENSION BOOT 13000526 1
6.1.11.1 BOLT M8X20 - DIN 933-8.8 20200150 4
6.1.11.2 NUT M8 DIN 934 - SP 20200119 4
6.1.11.3 SEAL CAP M8 16103699 4
6.1.11.4 KNURLED KNOB 13107842 1
6.2 ANCHOR & BEARING A SS'Y FA90 13204037 1
6.2.1 LOCKNUT M6 - DIN 985 20100400 2
6.2.2 BOLT M6X12 - DIN 933-8.8 20100160 2
6.2.3 ANCHOR TUBE WELDMENT Ø44 13204045 1
6.2.4 BEARING HOLDER CAP UP - Ø90 13203781 1
6.2.5 BEARING HOLDER CAP DOWN - Ø90 13203799 1
6.2.6 BEARING 17X35X10 - 6003 LLU 13201066 1
6.2.7 SEEGER RING Ø17X1 20101333 1
6.2.8 HOSE CLAMP Ø80 - 100MM 03200250 1
7 HW KIT FOR FA EXTENSION 360° 13000518 1
7.1 LOCKNUT M6-DIN 985-A2 20101960 4
7.2 BUT.HEAD CAP SCREW WITH FLANGE M6X16-A2 20109146 4
8 DROP Ø160 FOR EXTENSION BOOT 13000492 1
