ROXELL - 031 - 0516
FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-22
FIGURE 24.
(m)H
0 3 6 9 12 15 18 21 24
1
2
3
4
L(m)
MODEL 90 MODEL 125
(m)H
0 3 6 9 12 15 18 21 24
1
2
3
4
L(m)
GRAPH WITH MAXI MUM LENGTHS - MODEL 90/125 -
CDS BROILER CAGE
LC (5,4T)
HC (10T)
GRAPH WITH MAXIMUM LENGTHS - MOD. 90 - HEAVY DUTY AUGER
(HD)
Max. 3m.
STANDARD AUGER HORIZONTAL PART = HEAVYDUTY AUGER (HD)
Used for long distances.
FIGURE 25.
(m)H
0 3 6 9 12 15 18 21 24 27 30 33 36 39 42 45 48 51 54 57 60
1
2
3
4
5
6
7
L(m)
1,5 KW 450 RPM - HORIZONTAL LENGTH
For tandem*
MAX. 60M
