ROXELL - 031 - 0516
FLEX-AUGER - COMPONENTS
II-72
EXTENSION BOOT FOR OVERHEAD FA125- 03701228
6
7
1
2
5
3
Key Name Part Nr.
1 BOOT ASSEMBLY FA 125 03700531
2 EXTENSION PLATE Ø160 GALVA 13109525
3 DROP ø160 FOR EXTENSION BOOT 13000492
4 CONNECTION PLATE F/DROP 14916098
5 TUBE ANCHOR WELDMENT Ø125 14916527
6 TUBE CONNECTOR KIT 03700382
7 ANCHOR + BEARING ASS'Y FA125 13701016
4
