Roxell FLEX-AUGER FA 75 - MAXIMUM CABLE LENGTHS TO THE MOTORS

ROXELL - 031 - 0516
FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-77
MAXIMUM CABLE LENGTHS TO THE MOTORS
Calculation method: IEC-HD 60364-5
Cable type: PVC – XLPE – Silicon
Placing: Open cable trough
Materials used: Schneider Electric GV2 motor protections
Please be aware that you have to follow the local regulations for your country!
Motor Power (kW) Net voltage Protection Max. cable length (m) Wire gauge (mm²)
0.18
1x230V 50Hz GV2ME07
0-110 1.5
111 - 185 2.5
186 - 297 4
3x230V 50Hz GV2ME06
0-174 1.5
175 - 290 2.5
291 - 464 4
3x400V 50Hz GV2ME05
0-492 1.5
493 - 821 2.5
822 - 1314 4
0.22
3x220V 60Hz
3x230V 60Hz
GV2ME06
0-167 1.5
168 - 279 2.5
280 - 446 4
3x380V 60Hz
3x400V 60Hz
GV2ME05
0-471 1.5
472 - 785 2.5
786 - 1257 4
0.25
1x230V 50Hz GV2ME07
0-110 1.5
111 - 185 2.5
186 - 297 4
3x230V 50Hz GV2ME06
0-174 1.5
175 - 290 2.5
291 - 464 4
3x400V 50Hz GV2ME05
0-492 1.5
493 - 821 2.5
822 - 1314 4
0.37
1x230V 50Hz GV2ME08
0-69 1.5
70 - 116 2.5
117 - 185 4
3x230V 50Hz GV2ME07
0-111 1.5
112 - 185 2.5
186 - 297 4
3x400V 50Hz GV2ME06
0-308 1.5
309 - 513 2.5
514 - 821 4
0.45
3x220V 60Hz
3x230V 60Hz
GV2ME07
0-107 1.5
108 - 178 2.5
179 - 285 4
3x380V 60Hz
3x400V 60Hz
GV2ME06
0-294 1.5
295 - 491 2.5
492 - 785 4
0.55
3x230V 50Hz GV2ME08
0-69 1.5
70 - 116 2.5
117 - 185 4
3x230V 50Hz GV2ME07
0-111 1.5
112 - 185 2.5
186 - 297 4
3x400V 50Hz GV2ME07
0-197 1.5
198 - 328 2.5
329 - 525 4
3x400V 50Hz GV2ME06
0-308 1.5
309 - 513 2.5
514 - 821 4
