SPS-2000 Program Manual v1.30 Software Installation & SD Memory Utilities 37
Image Downloads
Key images can be added to function and PLU keys. (Images can also be used for keyscreen backgrounds
(viewed in REG mode where key locations are inactive.) Background Image display requires software
version 2.00x or later.) Images add style and usability to the SPS-2000 touch screen.
This procedure allows you to download images to the SPS-2000 where they can be added to keys in the S-
Mode Key Location program.
Tips for Getting Images Ready
The maximum image size for 1 x 1 size keys is 60 x 50 pixels. (2 x 2 size keys can be up to 120 x
100 pixels; 1 x 2 size keys can be 120 x 50 pixels; 2 x 1 size keys can be 60 x 100 pixels.) You will
need to use a graphic program such as Microsoft Paint to re-size larger images.
Images in many common formats can be used: i.e. .gif, .tif, .jpeg, .bmp. (.wmf format images cannot
be used.)
The length of the image file name must be less than 12-characters.
The image size for background images is 320 x 425 (this size will fill the entire panel). The
background image file name(s) should be “flist_imgxxx.jpg”, where xxx means the keylink number,
001 through 200. The extension must be .jpg (with lower case). To display the background image,
you must also set the DISPLAY BACKGROUND IMAGE option to YES. View this option by
touching the PGM button from the KEY RELOCATION screen.
A large selection of clip art can be accessed without charge from Microsoft Office Online at
http://office.microsoft.com/clipart/default.aspx?lc=en-us
.
CRS is preparing a library of common key images for use on the SPS-2000. Go to the SPS-2000
product page of the dealer area of www.crs-usa.com
to access these images.
