SPS-2000 Program Manual v1.30 S Mode Programming 53
Key Relocation (V3.0 and later)
Note: The Key Relocation screen was re-designed for ease of use beginning at software version 3.0. Tabs
now separate four functions: PGM, DESIGN, LIST, and SELECT SCREEN. The multi-check and auto
select options are functional beginning at version 3.00c.
The PGM Tab
The keylink set here will display after
entries for the initial keylink are satisfied
or the keylink is exited.
The value entered in the “number of choice”
field will determine the number of entries
before the keylink is automatically closed.
For example, if “2” is set here, after 2 entries,
the keylink will automatically close.
• If the DONE key is enabled and you set
“0” here, unlimited keylink entries will be
accepted. When the DONE key is pressed,
the previous keylink will display.
• If the DONE key is enabled and you wish
to advance to the keylink set in the
“FUNCTION LIST KEY LINK” field, set the
“NUMBER OF CHOICE:” field to a value of
“99”.
If YES, the keylink will ask for the
quantity of items.
The DISPLAY BACKGROUND IMAGE
option is available at version 2.01b or later.
Note that you must also download the
image. See “Image Downloads” on page 33.
Touch Copy to copy the keys on this screen
to a range of other screens.
Touch multi check if you wish to
assign the same attributes to a group of
locations at the same time. Touch as
many positions as you wish and then
make
our selection.
