Samsung RT4401-48A - Figure 3. System External Interface (RRH Only); Figure 4. System External Interface (with Clip-On: Antenna + AC-DC Power Unit)

Chapter 1 Before Installation
RT4401-48A Installation Manual v3.0 3
Copyright © 2019, All Rights Reserved.
Figure 3. System External Interface (RRH only)
Figure 4. System External Interface (with Clip-on: Antenna + AC-DC Power Unit)
DC_PWR
Ground Terminal
UDA
L0
L1
RET
AC_PWR
ANT 4
ANT 3
ANT 2
ANT 1
DC_PWR
Ground Terminal
UDA
L0
L1
RET
