Samsung RT4401-48A - Figure 51. Fixing Rrhs on the 3 Sector Pole Type (2)

Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 53
Copyright © 2019, All Rights Reserved.
Figure 51. Fixing RRHs on the 3Sector Pole Type (2)
When installing the RRH, the tilting angle pointer of the unit bracket should point
to 0°.
3 Fix the RRH-1 and RRH-2 in the same way as the RRH-0.
[Angle pointer position for unit bracket with
0° tilt when installing the RRH]
Tilting angle scale of the unit bracket
M8 Hex. Bolt
(Washer Assembly)
1
2
RRH-0
