Samsung RT4401-48A - Figure 59. Fixing Rrhs on the Pole (1)

Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 60
Copyright © 2019, All Rights Reserved.
Figure 59. Fixing RRHs on the Pole (1)
2 Place the unit bracket on the fixing grooves of the mounting bracket and push
the unit bracket down to fix the RRH-0 in place.
M6 Torx Screw
Unit Bracket
RRH-0
2
1
[Top View]
RRH-1
RRH-2
