Samsung RT4401-48A - Figure 43. RRH Swivelling Adjustment (2)

Chapter 2 Installing System
RT4401-48A Installation Manual v3.0 45
Copyright © 2019, All Rights Reserved.
Figure 43. RRH Swivelling Adjustment (2)
3 Fix the RRH using the working tools.
[Right Swivelling Adjustment]
[Left Swivelling Adjustment]
[Left Swivelling 30° Example]
[Right Swivelling 30° Example]
